Because of the way they specifically work, hydraulic truck cranes are different compared to other crane types. As opposed to utilizing a winch in order to wind up cables to provide the lifting force, hydraulic cranes utilize oil instead. Since oil is a fluid that retains its volume, it is incompressible. Thus, this means it is among the most ideal types of fluids for pushing pistons towards the direction the force is going to be exerted.
The hydraulic pump creates a pressure that moves the piston. This action is maneuvered by the driver utilizing the controls in his cab. Typically, hydraulic truck cranes use a pump that has 2 gears.
Since the actual crane itself is mounted on a truck, it can travel many distances from job to job and there is little dismantling involved. The truck crane has a single engine which controls both the truck and the crane.
Other Components
Boom Telescope: The boom telescope allows the boom to retract or extend thanks to hydraulics.
Jib: The jib is a latticed structure which extends from the boom.
Boom Swing: Boom swings have a large roller or ball attached to the carrier. It is able to swing 360 degrees in both directions. Hydraulic mechanisms provide swings at varying speeds and control the swing in order to rotate the turntable gearbox.
Outrigger: The outrigger is a unit that helps the crane maintain its balance by using hydraulics to lift the truck.
Load Movement Indicator: The load movement indicator is lights which flash in order to warn the driver that maximum weight is approaching.
Pump: The pump's purpose is to steer the outrigger.
Steel Cables: Steel reinforced cables run through the boom and the jib. They can generate up to 14,000 lbs. or 6350 kg.
Boom Elevation: The crane's boom ascends utilizing double hydraulic cylinders that allow for raising and lowering materials.
Rotex Gear: The rotex gear is operated by hydraulics and situated underneath the cab. It enables the boom to swivel on this gear.
