Performance
The overall result of how well the equipment's functions work together is categorized by the performance of the equipment. The equipment's overall effectiveness is determined by a combination of visibility, lifting speed, capacity and user-friendliness.
The working hydraulics and the engine go through extreme lifting and this puts intense demands on the machine. The lifting component is only a part of the operating cycle. Prior to the machinery being able to load or unload, the demands are placed on effective brakes, tight turning radius with high pulling process and precise control. All of these functions should be able to work in an optimum fashion, even after heavy usage.
Engine
Each empty container handler is made with a straight six cylinder turbo charged engine equipped with an intercooler. The engines are adapted to the particular working conditions of empty container handling. These conditions consist of high power and high torque levels at low engine speeds.
Currently in the business, the engines of existing units follow the stringent legal environment demands. The engines provide low vibration and noise levels, low exhaust emission levels, low fuel use characterize all engine alternatives.
Transmission
All container handlers have been made with extremely durable hydrodynamic transmission systems. For quick acceleration with a minimum of "clutch-slip" the transmission has included torque converter and gearbox. The gear changing is electrically attained by solenoid valves. These provide 3 forward and 3 reverse gears which are controlled by means of a multifunction lever that is easily operated.
Drive Axle
The drive axles are designed to handle the extreme and tough working environments in ports and in terminals. All axles have reduction in 2 stages - differential and hub reduction. These features guarantee a minimum of strain on the transmission system. Moreover, the drive axles are fitted with a hydraulic braking system.
Service Brake System
Wet Disc Brakes that have oil cooled discs that are alternately fixed to and rotating with the hub equip all empty container handlers. Once the brakes are engaged, the discs are pressed together by hydraulic pressure from the brake pedal. This provides effective braking to the model. The system could deal with heavy loads over a long period of time and is practically maintenance free. This particular system requires no need for brake adjustments and provides no fade.
